MS-S300 comes with 1,000 cd/? calibration to make it the best solution for diagnostic imaging of DR, CT, MRI etc. The brighter screen dramatically increases the number of perceptual grayscale steps to improve visibility of structures. Diagnostic reading will be much more efficient.
| Manufacturer | JVC |
|---|---|
| Condition | New |
| Screen Technology/Type | 21.3-inch, monochrome, TFT, IPS technology |
| Screen Size (diagonal) | 324 mm x 433 mm |
| Display Resolution | 1536 x 2048(Independent Sub-pixel Drive technology ON : 1536 x 6144) |
| Pixel Pitch | 0.2115 mm x 0.2115 mm |
| Viewing Angle (H, V) | 178° vertical and horizontal |
| Maximum Luminance | 2000 cd/m² (typ.) |
| Calibrated Luminance | 500 cd/m² / 1000 cd/m² (calibrated) |
| Contrast Ratio | 1500:1 (typ.) |
| Video Input Connectors | DVI-D (DVI 1.0 compliant) DisplayPort (DisplayPort 1.2a compliant) |
| Power Input Requirements | 100V – 240 V 50/60 Hz |
| Power Consumption | 35W (typ.) |
| Dimensions with Stand (W x H x D) | Landscape : 493 mm x 451.3 / 546.3 mm x 196.5 mm Portrait : 361.5 mm x 517 / 612 mm x 196.5 mm |
| Net Weight with Stand | approx. 10.2 kg |
| Mounting Options | VESA standard (100 mm x 100 mm) |
| Certifications | ANSI/AAMI ES60601-1 (2005) + A1 (2012), CAN/CSA-C22.2 No. 60601-1 (2014), CE (EN60601-1, EN60601-1-2), RCM, FCC Part15 subpart B Class B, ICES-003-B, VCCI-B, J-Moss, RoHS, EAC |
| Modality | Diagnostic |
